A turbo blanket order should start with the turbine housing and operating conditions, not simply a size label or an outer-fabric color.
BSTFLEX is a turbo blanket manufacturer offering standard patterns and custom-made insulation for turbocharger turbine housings. Our turbo heat shield blanket range includes titanium, carbon, aluminized fabric and silicone-coated fabric outer covers, with an optional embossed metal foil layer available to customer requirements.
For an OEM project, a branded aftermarket range or a turbo kit, the purchasing specification needs to describe the complete blanket: housing coverage, insulation construction, outer finish, fastening and packaging. Send your drawing or sample reference with the intended operating conditions to start a project review.
The turbine housing is the starting point for fitment. Record its external dimensions and shape, then identify the inlet and outlet connections, wastegate arrangement and available installation space. For a vehicle-specific application, include the turbocharger part number as well as the vehicle model, model year and engine.
BSTFLEX offers patterns including T25/T28, T3, T3/T4, T4 and T6. These designations help identify a product family; they should not replace a dimensional check. An internally wastegated housing also needs appropriate clearance around the actuator and moving linkage.
For a custom turbo blanket, mark the areas to be insulated and the areas that must remain accessible. Drawings and installed photographs can make these requirements clearer than a turbo model name alone.
The BSTFLEX titanium turbo blanket uses a basalt/lava-fiber textile exterior. Titanium is the product-range name here, not a statement that the cover is made from metallic titanium.
Specify this option when your product brief calls for the lava-fiber finish. The internal insulation, edge materials and fastening can be discussed separately rather than treating the exterior as a complete construction specification.
Our carbon fiber turbo heat shield blanket provides a carbon fabric outer cover with a black woven appearance.
For purchasing, distinguish carbon fabric from a black silicone-coated cover. They are separate material options even when both are sold as black turbo blankets. Include the required fabric finish and any surface-treatment requirements in the order specification.
The aluminized turbo blanket is the option for a metallic-faced fabric exterior.
Confirm the backing fabric and facing construction when comparing quotations. An aluminized fabric cover is not the same component as a separate embossed metal foil layer; a requirement for one should not be assumed to specify the other.
Our silicone-coated fiberglass turbo blanket offers a coated fabric exterior with color options available on request.
For a branded product range, agree the color reference together with the material specification. The coating, underlying fabric and internal insulation need to be selected for the intended operating conditions, not by appearance alone.
BSTFLEX can add embossed metal foil to a custom turbo heat shield blanket according to the customer's requirements. This is an optional construction feature, not a standard layer included in every blanket.
For a defined design, provide the metal grade, nominal thickness, embossing pattern and required coverage area. A marked drawing should identify the intended layer position and any restrictions around seams, edges or attachment points. When these details have not yet been determined, send the design objective and a reference sample for review.
The foil arrangement should be agreed with the complete blanket construction. Do not assume that adding a metal layer automatically establishes a higher temperature rating or a particular surface-temperature reduction.
A useful RFQ separates the turbine-housing temperature from the desired blanket outer-surface temperature. State continuous and peak conditions, where each temperature is measured, and the expected operating duration. Also identify any nearby component whose temperature limit matters to the project.
The outer fabric is one part of the assembly. The hot-face lining, insulation core, seams, edge binding and fastening must be considered together. Ask for the proposed construction rather than comparing turbo blanket suppliers on an exterior material name alone.
Define acceptance criteria before sample evaluation. For example, identify the measurement location, engine operating condition and required clearance, rather than requesting an unspecified percentage of heat reduction.
Start with an agreed design brief. Provide the housing information, thermal requirements, preferred outer cover and any metal foil details. For an existing design, identify which features must be retained and which may be changed.
Evaluate the sample in the intended installation. Check coverage, closure position, access to connections and clearance around moving components. Where thermal performance is part of the purchase specification, agree the validation conditions and responsibilities before approval.
Release a defined specification for production. Record the accepted materials, key dimensions, fastening arrangement, appearance and packaging. Identify critical inspection points so that sample approval becomes a practical reference for subsequent orders.
BSTFLEX supports customer-specific manufacturing and agreed inspection requirements. Our quality control and documentation information covers material checks, sewn-assembly workmanship, final inspection and batch traceability. Specify the reports or conformity documents required for your order at the quotation stage.
BSTFLEX offers custom logos and packaging for turbo blanket orders. For a private-label program, supply your artwork, preferred logo position, packaging format and product-identification requirements together with the technical brief.
A practical approach is to separate the housing pattern from the commercial variants. For example, a buyer may request quotations for titanium and silicone-coated versions of the same intended fitment. Each version should still have its own agreed material specification and sample approval.
Request pricing against a defined construction and quantity. Include the initial order, anticipated repeat demand and delivery requirement so that sampling, production and packaging needs can be reviewed together.
Yes. Send the available drawing or sample reference, along with the intended application and required changes. For a sample-based project, identify whether the objective is to reproduce the fit, change the materials or revise both. Feasibility and the proposed construction are confirmed during the project review.
Yes. State the required options, such as titanium, carbon, aluminized fabric or silicone-coated fabric. Request a separate construction description for each quotation so that the comparison includes the internal materials and hardware as well as the exterior.
These depend on the design, material requirements, order quantity and customization involved. Send the required quantity and delivery date for confirmation. A new pattern or special material arrangement may require sample review before the production schedule is finalized.
Use the following information to prepare an RFQ:
| RFQ item | Information to provide |
|---|---|
| Turbo identification | Manufacturer, turbo model and part number; vehicle and engine details where relevant |
| Housing and installation | Drawing, dimensions, photographs, wastegate arrangement and available clearance |
| Thermal requirements | Continuous and peak conditions, measurement locations and any acceptance target |
| Outer cover | Titanium, carbon, aluminized fabric or silicone-coated fabric; finish or color requirement |
| Embossed metal foil | Whether required; metal grade, thickness, pattern, position and coverage if already specified |
| Construction and branding | Insulation requirements, fastening preference, logo, labeling and packaging |
| Purchasing requirements | Sample quantity, initial order, anticipated repeat demand, delivery date and required documents |
Send your turbo housing drawing, preferred materials and order quantity to BSTFLEX for a project-specific quotation.
Request a Custom Turbo Blanket Quote or browse the turbo heat shield blanket range to select an existing product as the starting point.
